Air Conditioner Case with Blower for 1988 Mercedes-Benz 300E
No.
Part # / Description / Price
Price
23
Parts Kit, Heat Exchanger
Mercedes-Benz
Mercedes-Benz Notes: WITH HEATING WATER FEED IN TOP OF HEAT EXCHANGER; UP TO 4/90
23
Parts Kit, Heat Exchanger Mercedes-Benz
Mercedes-Benz Notes: WITH HEATING WATER FEED IN BOTTOM OF HEAT EXCHANGER; FROM 4/90
32
Parts Kit, Piping Mercedes-Benz
Mercedes-Benz Notes: WITH HEATING WATER FEED IN BOTTOM OF HEAT EXCHANGER; FROM 4/90
USED WITHOUT DUST FILTER
USED WITHOUT DUST FILTER
Description: Heat exchanger pipes.
32
Parts Kit, Piping Mercedes-Benz
Mercedes-Benz Notes: WITH HEATING WATER FEED IN TOP OF HEAT EXCHANGER; UP TO 4/90
Description: Heat exchanger pipes.
32
Parts Kit, Piping Mercedes-Benz
Mercedes-Benz Notes: ONLY USED WITH DUST FILTER
Description: Heat exchanger pipes.
47
MSRP $1.40
$1.16
68
Housing, Air Conditioner Mercedes-Benz
Mercedes-Benz Notes: USED WITHOUT DUST FILTER
Description: Lower part to 124 830 83 62.
68
Housing Mercedes-Benz
Mercedes-Benz Notes: ONLY USED WITH DUST FILTER
Description: Lower part to 124 830 70 62, 124 830 71 62. Lower part to 124 830 70 62,124 830 80 60.
78
89
MSRP $3.70
$3.22
92
Insulating Sleeve Mercedes-Benz
Mercedes-Benz Description: To 000 546 83 40. To 000 546 79 40. To 000 546 583 40. Charge control. Electric cable to pressure switch. Low pressure switch.
101
Grommet Mercedes-Benz
Mercedes-Benz Description: Blower. Electric cable thru fire wall. Fuel pump branch-off to luggage compartment floor. Automatic transmission branch-off. Electric cable thru tunnel. Scuff protection for electric cables left.
107
107
Valve Mercedes-Benz
Mercedes-Benz Notes: ONLY WITH R-134-A REFRIGERANT
Description: (expansion valve).
MSRP $109.00
$83.85
MSRP $109.00
$83.85
110
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
111
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
143
152
152
173
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Inductive pickup to 008 545 08 28. Belt lock,left front seat to 008 545 08 28. Only for use with air conditioner. Throttle body to 008 545 08 28. To 008 545 08 28, 008 545 09 28. To 008 545 10 28.
176
Plug Pin Mercedes-Benz
Mercedes-Benz Description: 4MM. 4.0mm2. Fan. 4.0mm2. TO 008 545 10 28. 4.0mm2.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
182
206
209
Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Bracket to heater case. N 14128 6,3X16-R
Diameter: 6,3mm
Thread code letter: R. Attachment cover left. Bracket with recirculating pump to side member,front. Control unit to fire wall abs. Screening to partition panel 6.3x16.
Diameter: 6,3mm
Thread code letter: R. Attachment cover left. Bracket with recirculating pump to side member,front. Control unit to fire wall abs. Screening to partition panel 6.3x16.
MSRP $1.90
$1.60
MSRP $1.90
$1.60
221
Grommet Mercedes-Benz
Mercedes-Benz Notes: WITH HEATING WATER FEED IN BOTTOM OF HEAT EXCHANGER; FROM 4/90
Description: Return. Heat exchanger pipes thru front panel.
221
Grommet Mercedes-Benz
Mercedes-Benz Notes: WITH HEATING WATER FEED IN TOP OF HEAT EXCHANGER; UP TO 4/90
Description: Return. Heat exchanger pipes thru front panel.
227
233
MSRP $1.20
$1.02
