Refrigerant Line Arrangement for 2020 Mercedes-Benz S63 AMG
No.
Part # / Description / Price
Price
15
O-Ring
Mercedes-Benz
Mercedes-Benz Description: To evaporator. Line to condenser. Condenser and connecting point 1/2". Condenser to compressor. Pipe line to refrigerant compressor. Piping to refrigerant compressor. Between evaporator and expansion valve.
MSRP $8.75
$7.54
MSRP $8.75
$7.54
55
O-Ring Mercedes-Benz
Mercedes-Benz Description: Lower. Condenser and connecting point 3/8". Condenser to connecting point and expansion valve. Pressure line to expansion valve. Refrigerant line to expansion valve and connecting point. Refrigerant line to chiller. Refrigerant line to condenser, expansion valve and refrigerant line . Refrigerant line to shutoff valve. T0 refrigerant line. Refrigerant line to refrigerant line, expansion valve and evaporator.
MSRP $10.50
$9.14
MSRP $10.50
$9.14
65
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Description: Line to suspension strut. Piping mount. Refrigerant line and holder mount.
MSRP $3.00
$2.61
MSRP $3.00
$2.61
80
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. High-pressure line. Cover, service connection, high pressure, air conditioning system. Filling connection m10x1. High-pressure side M10X1. To refrigerant line. Valve.
MSRP $6.75
$5.80
MSRP $6.75
$5.80
90
MSRP $1.70
$1.45
155
O-Ring Mercedes-Benz
Mercedes-Benz Description: Intake side. Upper. Expansion valve connection. Line to check valve. Piping to refrigerant compressor. Refrigerant line to connecting point and compressor 3/4". Evaporator. Refrigerant line to expansion valve .
MSRP $5.50
$4.64
MSRP $5.50
$4.64
165
Valve Element Mercedes-Benz
Mercedes-Benz Description: Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
MSRP $19.50
$16.68
MSRP $19.50
$16.68
170
Power Steering Pump Bolt Mercedes-Benz
Mercedes-Benz Description: M8x30. Bracket to transmission cover. Bracket to transmission m 8x30. Slave cylinder to transmission case. Front exhaust pipe to transmission m8 x 30. Bracket to mounting plate or to transmission.
MSRP $4.00
$3.48
MSRP $4.00
$3.48
175
MSRP $2.50
$2.18
180
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. Filling connection. Low-pressure line. Seal. Suction line. Cover, service connection, low pressure, air conditioning system. Low-pressure side M8X1. To refrigerant line. Valve.
MSRP $12.00
$10.44
MSRP $12.00
$10.44
315
Spacer Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Between the lines. Purge line to engine. Vacuum line to fuel line.
400
MSRP $316.00
$243.81
460
480
550
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Pressure line to rear evaporator. M6x34. Refrigerant line to condenser. Hose line mount.
804
867
Buffer Mercedes-Benz
Mercedes-Benz Description: To front module. Mounting, refrigerant line. To compressor. Vibration damper. At front module. To upper holder. Pump mounting.
869
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
877
Nut-And-Washer Assembly Mercedes-Benz
Mercedes-Benz Description: Wiper system to firewall. M8
Diameter: 8mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 23mm
Width across flats: 13mm. Bracket to body shell. Holder to left wheel well. Wiper system mount to buffer. Wiper system to partition. Nut, fastening, wiper, wiper system. Elastomer bearing mount to body-in-white, left.
Diameter: 8mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 23mm
Width across flats: 13mm. Bracket to body shell. Holder to left wheel well. Wiper system mount to buffer. Wiper system to partition. Nut, fastening, wiper, wiper system. Elastomer bearing mount to body-in-white, left.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
907
Line Fastener Mercedes-Benz
Mercedes-Benz Description: Fuel line mount. Fuel leak line. Fuel line to left main floor. Purge line fastening. Purge line to front left longitudinal member. Fuel line to front-end assembly. Purge line mount. T0 refrigerant line. Fuel lines to side member 12 mm+8 mm.
MSRP $3.90
$3.34
MSRP $3.90
$3.34
954
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Left and right flap paneling to hinge.
MSRP $1.40
$1.16
MSRP $1.40
$1.16
968
Jaw Clamp Mercedes-Benz
Mercedes-Benz Description: At motor. 14-16 mm. Left rear brake cable. 14-16 mm. Line to line. 14-16 MM. Oil line connection. 14-16 mm.
MSRP $8.00
$6.82
MSRP $8.00
$6.82
992
MSRP $3.50
$3.05
