Rear Axle Carrier for 2020 Mercedes-Benz GLC63 AMG S
No.
Part # / Description / Price
Price
10
MSRP $935.00
$700.00
20
Axle Sub-Frame Suspension
Mercedes-Benz
Mercedes-Benz Description: Rear axle carrier to front frame floor assembly. Rear subframe to frame floor unit, front. Front left and right.
30
Axle Sub-Frame Suspension Mercedes-Benz
Mercedes-Benz Description: Rear axle carrier to rear frame floor assembly. Rear subframe to frame floor unit,rear. Rear left and right.
40
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Spring link to rear axle bracket left. Spring link to left rear axle carrier. Spring control arm to rear subframe.
MSRP $29.50
$23.10
MSRP $29.50
$23.10
50
Rear Axle Diff Mount Mercedes-Benz
Mercedes-Benz Description: Axle housing to rear axle carrier, rear left and right. Rear axle differential to carrier, rear.
MSRP $32.00
$25.08
MSRP $32.00
$25.08
65
MSRP $29.50
$23.10
70
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Rear axle transverse guide. Adapter at left and right to rear axle differential. To left and right transmission.
MSRP $1.10
$0.94
MSRP $1.10
$0.94
75
Hexalobular Head Screw Mercedes-Benz
Mercedes-Benz Description: Rear axle differential to left rear crossmember. M14x1,5x70. Rear axle differential to rear cross brace. Rear axle differential to left rear cross bridge. Extension to cross-bar at left rear. Left and right adapter to bearing bracket. Bearing bracket to left and right rear axle differential bearing. Rear axle differential to right rear crossmember.
MSRP $2.60
$2.23
MSRP $2.60
$2.23
78
Front Support Washer Mercedes-Benz
Mercedes-Benz Description: Crossmember mountDiameter: 14mmInside diameter: 14mmOutside diameter: 30mmMaterial thickness: 2,5mm. Support to left and right bodyDiameter: 14mmInside diameter: 14mmOutside diameter: 30mmMaterial thickness: 2,5mm. Bearing bracket to left and right rear ax ...
MSRP $3.00
$2.61
MSRP $3.00
$2.61
130
Screw W Washer Assembly Mercedes-Benz
Mercedes-Benz Description: Rear axle carrier to front frame floor assembly. Rear subframe to frame floor unit, front. Screwith bolt, decoupling element, front, rear axle carrier.
MSRP $18.50
$15.95
MSRP $18.50
$15.95
240
Hexalobular Head Screw Mercedes-Benz
Mercedes-Benz Description: Rear axle differential to front cross brace. M10x93. Adapter to rear axle centerpiece.
MSRP $8.75
$7.54
MSRP $8.75
$7.54
250
Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 1 mm. Differential to cross stabilizer front 1 mm. 1 mm. Rear axle differential to front cross brace 1 MM. 1 MM. As required 1.0 mm. 1 mm. As required, no. Of notches:. 1 mm. As required 1.00 mm. 1 mm.
MSRP $4.70
$4.06
MSRP $4.70
$4.06
250
Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 3 mm. Differential to cross stabilizer front 3 mm. 3 mm. Rear axle differential to front cross brace 3 MM. 3 MM. As required 3.0 mm. 3 mm. As required, no. Of notches:. 3 mm. As required 3.00 mm. 3 mm.
MSRP $6.00
$5.22
MSRP $6.00
$5.22
250
Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 4 mm. Differential to cross stabilizer front 4 mm. 4 mm. Rear axle differential to front cross brace 4 MM. 4 MM. As required 4.0 mm. 4 mm. As required, no. Of notches:. 4 mm. As required 4.00 mm. 4 mm.
MSRP $5.75
$4.93
MSRP $5.75
$4.93
250
Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 2mm. Differential to cross stabilizer front 2mm. 2mm. Rear axle differential to front cross brace 2mm. 2mm. As required 2.0 mm. 2mm. As required, no. Of notches:. 2mm. As required 2.00 mm. 2mm.
MSRP $5.50
$4.64
MSRP $5.50
$4.64
290
Hexalobular Head Screw Mercedes-Benz
Mercedes-Benz Description: Rear axle differential to crossmember with damper. Rear axle differential to left rear crossmember M014X1.5X115. Rear axle differential to rear cross brace. Bearing to rear axle. Rear axle differential to left rear cross bridge. To rear axle carrier.
300
Adjusting Plate Mercedes-Benz
Mercedes-Benz Description: Cross bridge, rear left and right to rear axle carrier. 2,5 MM. Left, with 3 notches 2,5 MM. 2,5 MM.
300
Adjusting Plate Mercedes-Benz
Mercedes-Benz Description: Cross bridge, rear left and right to rear axle carrier. 1,5 MM. Left, with 2 notches 1,5 MM. 1,5 MM.
300
Adjusting Plate Mercedes-Benz
Mercedes-Benz Description: Cross bridge, rear left and right to rear axle carrier. 0,5 MM. Left, with 1 notch 0,5 MM. 0,5 MM.
