Compressor and Wiring for 2016 Mercedes-Benz C63 AMG S

10

Compressor Unit

099-320-00-04

Mercedes-Benz

Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART

Description: Air suspension.

MSRP $1,150.00

$856.25

MSRP $1,150.00

$856.25

20

Suction Hose

205-997-00-52

Mercedes-Benz

Description: Air suspension.

MSRP $69.00

$54.12

MSRP $69.00

$54.12

30

Holder

205-320-01-43

Mercedes-Benz

Description: To compressor.

View Details

40

Window

111-990-36-40

Mercedes-Benz

Description: HEATER CASE TO FIRE WALLDiameter: 6mmInside diameter: 6,4mmOutside diameter: 22mmMaterial thickness: 1mm. TAIL LAMP TO REAR BODY PANELDiameter: 6mmInside diameter: 6,4mmOutside diameter: 22mmMaterial thickness: 1mm. COMPRESSORDiameter: 6mmInside diameter: ...

MSRP $10.50

$8.99

MSRP $10.50

$8.99

50

Buffer W Clearance Hole

2113270430

Mercedes-Benz

Description: Compressor to bracket. Compressor to holder. Compressor bearing. Top.

MSRP $3.50

$3.05

MSRP $3.50

$3.05

60

Compression Spring

2209930301

Mercedes-Benz

Description: Compressor.

MSRP $3.90

$3.34

MSRP $3.90

$3.34

70

Buffer W Clearance Hole

211-327-05-30

Mercedes-Benz

Description: Compressor to bracket. Compressor to holder. At cross member. Compressor bearing. Bottom.

MSRP $3.90

$3.34

MSRP $3.90

$3.34

80

Bearing Sleeve

000-992-22-50

Mercedes-Benz

Description: Compressor.

MSRP $3.70

$3.19

MSRP $3.70

$3.19

90

347764 - Springs, Suspension and Hydraulic Components: Nut for Mercedes-Benz Image

Ft Seat Air Bag Nut

000000-003477-64

Mercedes-Benz

Description: Air bags. 144 wheelbase. 170 wheelbase. Driver side. Passenger side. Reverse warning.

MSRP $2.80

$2.39

MSRP $2.80

$2.39

100

Spacer Bush

006-992-43-01-64

Mercedes-Benz

Description: Compressor to bracket. Compressor to holder.

View Details

120

Valve Block

099-320-00-58

Mercedes-Benz

Description: Air suspension. To compressor.

MSRP $392.00

$303.15

MSRP $392.00

$303.15

130

Connection Fitting

000-327-00-69

Mercedes-Benz

Description: Control unit. Compressed air line. To susp. Strut left and right front. To valve block 4 MM. Air spring, left and right. Left and right air suspension strut. Air suspension strut lh & rh.

MSRP $9.00

$7.83

MSRP $9.00

$7.83

140

Connection Fitting

221-328-00-65

Mercedes-Benz

Description: Pressure line to compressor. Compressed air connection. To valve block 6 MM. Compressed air line to compressor.

MSRP $15.00

$12.91

MSRP $15.00

$12.91

150

Screw

1669900012

Mercedes-Benz

MSRP $3.40

$2.90

MSRP $3.40

$2.90

155

Decoupling Element

000-998-19-47

Mercedes-Benz

Description: Valve block at bracket. To valve block.

MSRP $13.00

$11.24

MSRP $13.00

$11.24

160

Holder

230-546-25-43

Mercedes-Benz

Description: Wiring harness fastening in wheelh. TO WHEELHOUSE, LEFT
Diameter: 8mm (Fuss)
Inside diameter: 12mm
Outside diameter: 13mm. NOx sensor line mount to shield
Diameter: 8mm (Fuss)
Inside diameter: 12mm
Outside diameter: 13mm.

MSRP $3.70

$3.19

MSRP $3.70

$3.19

200

Compressed-Air Line

205-327-00-00

Mercedes-Benz

Description: Compressor to valve block.

MSRP $16.00

$13.78

MSRP $16.00

$13.78

210

Hexagon Nut

910112-008000

Mercedes-Benz

MSRP $3.00

$2.61

MSRP $3.00

$2.61

220

Hexagon Head Bolt

910105-008008

Mercedes-Benz

Description: Cross member to left front panel pillar.

MSRP $2.70

$2.32

MSRP $2.70

$2.32

300

Compressed-Air Line

2203271045

Mercedes-Benz

Notes: TO BE ADAPTED DURING ASSEMBLY

Description: Valve unit to left front susp. Repair size. 1520mm. Repair kit. 1520mm. Compressor to suspension strut (repair version). 1520mm. Repair solution: from valve block to left front suspension strut. 1520MM. Repair solution: From valve block to pressure reservoir. 1520MM.

MSRP $28.50

$22.44

MSRP $28.50

$22.44

310

Connecting Piece

000-327-01-69

Mercedes-Benz

Description: Repair size. To pressure line. Repair solution, front suspension strut.

MSRP $77.00

$60.72

MSRP $77.00
