Seat Adjustment for 2015 Mercedes-Benz ML 63 AMG®
No.
Part # / Description / Price
Price
50
MSRP $1,650.00
$1,237.50
50
MSRP $1,720.00
$1,287.50
50
MSRP $1,770.00
$1,325.00
50
MSRP $2,320.00
$1,737.50
100
MSRP $75.00
$58.74
120
Hexalobular Bolt
Mercedes-Benz
Mercedes-Benz Description: Mounting parts. 5x12 mm. Bracket mounting. 5x12 mm. Left. 5x12 mm.
MSRP $3.50
$3.05
MSRP $3.50
$3.05
150
Switch Block Mercedes-Benz
Mercedes-Benz Description: Lordotic support, right side. Left seat. Seat adjustment, right.
250
Self-Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Floor seat adjuster, left. Pivot bearing attachment to bodyshell, lh. Fastening, left seat frame.
MSRP $5.25
$4.50
MSRP $5.25
$4.50
250
Self-Tapping Screw Mercedes-Benz
Mercedes-Benz Description: M10X28
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Fastening reinforcement. Seat mounting. Front seat to cross member. At console. Console to floor. Front seat to console m8x28. Seat framework to floor. Left. Reinforcement to tunnel at front.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Fastening reinforcement. Seat mounting. Front seat to cross member. At console. Console to floor. Front seat to console m8x28. Seat framework to floor. Left. Reinforcement to tunnel at front.
MSRP $5.75
$4.93
MSRP $5.75
$4.93
300
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left seat. Driver's side.
MSRP $255.00
$197.37
MSRP $255.00
$197.37
300
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left seat. Co-driver's side.
300
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left seat.
300
Control Unit, Seats 1 Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Left seat.
MSRP $247.00
$190.92
MSRP $247.00
$190.92
300
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left seat.
900
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Seat adjustment control module driver side n32/1. 31-pin slk2.8. Rear seat control unit, blue n32/5, n32/6. 31-pin slk2.8.
MSRP $8.25
$6.99
MSRP $8.25
$6.99
901
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Steering column length adjustment motor m20/1. 4-pin jpt, mt3. Backrest adjuster m27/5, m28/5. 4-pin jpt, mt3. Fore-and-aft adjustment m27/1, m28/1. 4-pin jpt, mt3. Steering column adjustment motor m 20/1, m 20/2. 4-pin jpt, mt3. Forwards/backwards steering column adjustment m20/1. 4-pin jpt, mt3. Steering column adjustment motor m20/1,m20/2. 4-pin jpt, mt3. Seat adjustment motor m27/1-3 m28/1-3. 4-pin jpt, mt3. Steering column length adjustment motor n20/1. 4-pin jpt, mt3.
MSRP $6.25
$5.37
MSRP $6.25
$5.37
902
Lock Mercedes-Benz
Mercedes-Benz Description: Height adjustment motor TO A 220 545 96 28. Driver seat adjustment.
MSRP $3.00
$2.61
MSRP $3.00
$2.61
902
Plug Mercedes-Benz
Mercedes-Benz Description: Height adjustment motor TO A 220 545 96 28. 4-PIN JPT, MT3. Motor side flap rear shelf 4-pin m49/1. 4-pin jpt, mt3. Belt feeder,left a 10. 4-pin jpt, mt3. Fore-and-aft adjustment m27/1. M28/1. 4-pin jpt, mt3. Seat height adjustment,rear m27/2, m28/2. 4-pin jpt, mt3. Driver fore/aft seat adjustment motor m27/1. 4-pin jpt, mt3. Seat adjuster plug-connection x54. 4-pin jpt, mt3.
MSRP $6.50
$5.66
MSRP $6.50
$5.66
903
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Position sender unit s68/20. 2-pin mqs. Center seat belt buckle switch s68/14. 2-pin mqs. Connecting point, left speaker x18/13. 2-pin mqs.
MSRP $3.40
$2.90
MSRP $3.40
$2.90
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
