Rear Axle Mount for 2011 Mercedes-Benz R350
No.
Part # / Description / Price
Price
100
MSRP $1,770.00
$1,325.00
110
Repair Kit, Support Joint
Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Repair kit. Supporting joint lh.
MSRP $404.00
$312.18
MSRP $404.00
$312.18
115
Nut Mercedes-Benz
Mercedes-Benz Description: Suspension strut to spring linkDiameter: 16mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 34,5mmWidth across flats: 24mm. SHOCK ABSORBER TO LOWER CONTROL ARMDiameter: 16mmStrength / hardness class: 10Thread code le ...
MSRP $4.50
$3.92
MSRP $4.50
$3.92
115
MSRP $7.00
$5.95
130
MSRP $185.00
$143.19
135
Angular-Contact Ball Brg Mercedes-Benz
Mercedes-Benz Notes: OBSERVE WIS
Description: Rear wheel bearing. Front wheel bearing 90mm.
MSRP $105.00
$81.27
MSRP $105.00
$81.27
140
Retaining Ring Mercedes-Benz
Mercedes-Benz Description: Wheel bearing to left steering knuckle. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm. WHEEL BEARING TO WHEEL CARRIER LEFT. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm.
Inside diameter: 90mm
Material thickness: 3mm. WHEEL BEARING TO WHEEL CARRIER LEFT. 90X3 MM
Inside diameter: 90mm
Material thickness: 3mm.
MSRP $8.75
$7.54
MSRP $8.75
$7.54
200
Hex Nut W Flange + Piece Mercedes-Benz
Mercedes-Benz Description: Drive shaft to front wheel hub. M24x1.5. Rear axle shaft.
MSRP $19.50
$16.68
MSRP $19.50
$16.68
300
Transverse Control Arm Mercedes-Benz
Mercedes-Benz Notes: CAUTION: ONLY EXCHANGEABLE IN PAIRS UP TO IDENT. A 066 712
Description: Bottom right.
MSRP $690.00
$523.24
MSRP $690.00
$523.24
300
Transverse Control Arm Mercedes-Benz
Mercedes-Benz Notes: CAUTION: ONLY EXCHANGEABLE IN PAIRS UP TO IDENT. A 066 712
Description: Bottom left.
MSRP $790.00
$599.44
MSRP $790.00
$599.44
310
Rubber Bushing Mercedes-Benz
Mercedes-Benz Notes: IS NO LONGER DELIVERED, ORDER DELIVERY CONTENTS
Description: Left control arm. Lower control arm. Transverse control arm.
320
Bearing Element, Elastom Mercedes-Benz
Mercedes-Benz Description: Left control arm. Rear shock absorbers. Transverse control arm.
350
MSRP $122.00
$94.17
360
Protective Cap Mercedes-Benz
Mercedes-Benz Description: Bottom left transverse control arm at frame-type integral support. Left lower transverse control arm to integral carrier.
MSRP $3.70
$3.19
MSRP $3.70
$3.19
400
MSRP $175.00
$135.45
500
MSRP $184.00
$141.90
500
MSRP $175.00
$135.45
560
Nut Mercedes-Benz
Mercedes-Benz Description: Upper transverse control arm to bodyDiameter: 10mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 21,8mmWidth across flats: 16mm. Torsion bar linkage to torsion barDiameter: 10mmStrength / hardness class: 10Thread cod ...
MSRP $3.40
$2.90
MSRP $3.40
$2.90
570
MSRP $4.20
$3.63
570
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description:
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm.
MSRP $3.50
$3.05
MSRP $3.50
$3.05
600
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: RIGHT CONTROL ARM
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,FRONT
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,FRONT
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
600
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: On frame-type int. M14X95
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Hydropneumatic spring leg to spring control arm. Right control arm. Shock absorber to spring link. Control arm to frame,front. Lower transverse control arm to left wheel carrier. Shock absorber to left and right rear axle. Shock absorber mount, lower left. Trailing arm to rear axle, upper left and right.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Hydropneumatic spring leg to spring control arm. Right control arm. Shock absorber to spring link. Control arm to frame,front. Lower transverse control arm to left wheel carrier. Shock absorber to left and right rear axle. Shock absorber mount, lower left. Trailing arm to rear axle, upper left and right.
610
Nut Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Hydropneumatic spring leg to spring control arm. M14X1.5-10
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 21mm. Control arm to support. To left transverse control arm. Control arm to frame,front. Lower control arm. Suspension strut to supporting joint.
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 29,9mm
Width across flats: 21mm. Control arm to support. To left transverse control arm. Control arm to frame,front. Lower control arm. Suspension strut to supporting joint.
MSRP $7.00
$6.09
MSRP $7.00
$6.09
610
MSRP $7.00
$5.95
620
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M14X1,5X100-10.9
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. On frame-type int. Transverse control arm at bottom to integral carrier. Suspension strut to transverse control arm. Transverse control arm, rear, to frame-type integral support. Cross strut to integral carrier. Camber struts to wheel carrier. Trailing arm to rear axle, lower left and right.
MSRP $12.50
$10.59
MSRP $12.50
$10.59
620
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: LEFT CONTROL ARM. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,REAR. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSVERSE CONTROL ARM AT BOTTOM TO INTEGRAL CARRIER. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. CONTROL ARM TO FRAME,REAR. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSVERSE CONTROL ARM AT BOTTOM TO INTEGRAL CARRIER. 14X100
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
640
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: STRUT TO REAR SUBFRAME
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
640
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Torque strut to frame-type integral support, left and right. M12X1,5X60
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to rear subframe. Torsion bar to rear axle carrier. Inner. Left tie rod to wheel carrier. Suspension strut at bearing bracket.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to rear subframe. Torsion bar to rear axle carrier. Inner. Left tie rod to wheel carrier. Suspension strut at bearing bracket.
MSRP $6.00
$5.08
MSRP $6.00
$5.08
650
Rail Extension Nut Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Cross stabilizer front to side element.
650
Nut Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: M12X1.5-10
Diameter: 12mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 26mm
Width across flats: 18mm. Strut to rear subframe. Torsion bar to rear axle. Rod to shock absorber strut.
Diameter: 12mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Outside diameter: 26mm
Width across flats: 18mm. Strut to rear subframe. Torsion bar to rear axle. Rod to shock absorber strut.
MSRP $7.75
$6.67
MSRP $7.75
$6.67
660
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Strut rod to wheel carrier, left and right. M12X1,5X85
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to wheel bearing. Brake caliper to left wheel carrier. Left tie rod to wheel carrier. Spring link to left wheel carrier.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Strut to wheel bearing. Brake caliper to left wheel carrier. Left tie rod to wheel carrier. Spring link to left wheel carrier.
660
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
THE OLD PART MUST NO LONGER BE INSTALLED
THE OLD PART MUST NO LONGER BE INSTALLED
Description: STRUT TO WHEEL BEARING
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
MSRP $17.50
$15.23
MSRP $17.50
$15.23
670
Window Mercedes-Benz
Mercedes-Benz Description: Strut rod to left wheel carrier. Camber struts to wheel bearing. Strut rod to wheel carrier, lh.
MSRP $8.00
$6.82
MSRP $8.00
$6.82
700
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Notes: OBSERVE WIS
THE OLD PART MUST NO LONGER BE INSTALLED
THE OLD PART MUST NO LONGER BE INSTALLED
Description: Camber struts to rear subframe.
700
Eccentric Screw Mercedes-Benz
Mercedes-Benz Description: Camber strut to left rear axle carrier. Camber struts to rear subframe.
MSRP $15.50
$13.41
MSRP $15.50
$13.41
710
Window Mercedes-Benz
Mercedes-Benz Description: Tie rod to rear axle carrierDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. CAMBER STRUTS TO REAR SUBFRAMEDiameter: 12,1mmInside diameter: 12,1mmOutside diameter: 31mmMaterial thickness: 3mm. TIE ROD TO REAR SUBFRAMEDi ...
MSRP $0.30
$0.25
MSRP $0.30
$0.25
710
MSRP $6.00
$5.08
730
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: CAMBER STRUTS TO WHEEL CARRIER
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSMISSION TO SUBFRAME M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. TRANSMISSION TO SUBFRAME M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm.
730
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Upper left transverse control arm to body. M12X1,5X95
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing on rear axle carrier, front. Camber struts to wheel carrier. Transmission to subframe m12x1,5x95. Axle housing to rear subframe. Axle housing to rear axle carrier, rear. Torsion bar to rear axle carrier. Vibration absorber.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing on rear axle carrier, front. Camber struts to wheel carrier. Transmission to subframe m12x1,5x95. Axle housing to rear subframe. Axle housing to rear axle carrier, rear. Torsion bar to rear axle carrier. Vibration absorber.
MSRP $14.00
$12.18
MSRP $14.00
$12.18
800
Eccentric Screw Mercedes-Benz
Mercedes-Benz Description: Tie rod to rear-axle bracket, left and right. M12x1,5,78. Tie rod to rear subframe left. Tie rod to left rear axle carrier.
MSRP $12.00
$10.15
MSRP $12.00
$10.15
800
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Tie rod to rear subframe.
