Springs and Suspension, Front for 2011 Mercedes-Benz ML450
No.
Part # / Description / Price
Price
10
MSRP $750.00
$571.50
10
Air Spring Strut
Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Front left and right.
MSRP $1,870.00
$1,400.00
MSRP $1,870.00
$1,400.00
15
Connecting Sheet Mercedes-Benz
Mercedes-Benz Description: Left and right suspension strut. Cable on valve. To pressure reservoir. Compressed-air connection. Fuel rail. Pipe line to pressure accumulator.
MSRP $8.00
$6.82
MSRP $8.00
$6.82
100
MSRP $320.00
$247.68
110
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: TO DETERMINE THE FRONT SPRINGS, THE POINTS IN THE TABLE BELOW FOR EACH RESPECTIVE MODEL AND THE SPECIAL VERSIONS
INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
164.120/121 300
164.122/124 300 228 AUXILIARY HEATER 2
164.125 300 414 POWER GLASS SLIDING ROOF 2
164.156 275 615 BI-XENON W/ CURVE ILLUMINAT. FOR RH TRAFFIC 1
678 LT-ALLOY WHEELS W/ EMERG.RUNNING CHARACTER. 1
164.172 290 810 SOUND SYSTEM 1
164.172 + 494 291 846 PROTECTIVE SIDE MOLDING 1
164.175 292 U12 VELOUR 1
164.175 + 494 293
164.182 286
164.182 + 494 287
164.186 286
164.186 + 494 287
==============================================================================================================================
POINTS TOTAL FRONT SPRINGS
-277 A 164 321 03 04 REPLAC. IN A 251 321 05 04
278-302 A 164 321 01 04 REPLAC. IN A 251 321 03 04
303- A 164 321 02 04 REPLAC. IN A 251 321 04 04
==============================================================================================================================
ALSO USE: 1 X A 164 324 00 84
ALSO USE: 1 X A 164 324 00 84
Description: Color marking: 1 x light green.
MSRP $159.00
$122.55
MSRP $159.00
$122.55
110
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: TO DETERMINE THE FRONT SPRINGS, THE POINTS IN THE TABLE BELOW FOR EACH RESPECTIVE MODEL AND THE SPECIAL VERSIONS
INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
164.120/121 300
164.122/124 300 228 AUXILIARY HEATER 2
164.125 300 414 POWER GLASS SLIDING ROOF 2
164.156 275 615 BI-XENON W/ CURVE ILLUMINAT. FOR RH TRAFFIC 1
678 LT-ALLOY WHEELS W/ EMERG.RUNNING CHARACTER. 1
164.172 290 810 SOUND SYSTEM 1
164.172 + 494 291 846 PROTECTIVE SIDE MOLDING 1
164.175 292 U12 VELOUR 1
164.175 + 494 293
164.182 286
164.182 + 494 287
164.186 286
164.186 + 494 287
==============================================================================================================================
POINTS TOTAL FRONT SPRINGS
-277 A 164 321 03 04 REPLAC. IN A 251 321 05 04
278-302 A 164 321 01 04 REPLAC. IN A 251 321 03 04
303- A 164 321 02 04 REPLAC. IN A 251 321 04 04
==============================================================================================================================
ALSO USE: 1 X A 164 324 00 84
ALSO USE: 1 X A 164 324 00 84
Description: Color marking: 1 x yellow.
MSRP $134.00
$103.20
MSRP $134.00
$103.20
110
Helical Spring Mercedes-Benz
Mercedes-Benz Notes: TO DETERMINE THE FRONT SPRINGS, THE POINTS IN THE TABLE BELOW FOR EACH RESPECTIVE MODEL AND THE SPECIAL VERSIONS
INSTALLED ARE TO BE ADDED UP
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
164.120/121 300
164.122/124 300 228 AUXILIARY HEATER 2
164.125 300 414 POWER GLASS SLIDING ROOF 2
164.156 275 615 BI-XENON W/ CURVE ILLUMINAT. FOR RH TRAFFIC 1
678 LT-ALLOY WHEELS W/ EMERG.RUNNING CHARACTER. 1
164.172 290 810 SOUND SYSTEM 1
164.172 + 494 291 846 PROTECTIVE SIDE MOLDING 1
164.175 292 U12 VELOUR 1
164.175 + 494 293
164.182 286
164.182 + 494 287
164.186 286
164.186 + 494 287
==============================================================================================================================
POINTS TOTAL FRONT SPRINGS
-277 A 164 321 03 04 REPLAC. IN A 251 321 05 04
278-302 A 164 321 01 04 REPLAC. IN A 251 321 03 04
303- A 164 321 02 04 REPLAC. IN A 251 321 04 04
==============================================================================================================================
ALSO USE: 1 X A 164 324 00 84
ALSO USE: 1 X A 164 324 00 84
Description: Color code: 1 x light gray.
MSRP $142.00
$109.65
MSRP $142.00
$109.65
130
MSRP $187.00
$144.48
133
MSRP $19.50
$16.68
135
MSRP $16.00
$13.92
160
Nut Mercedes-Benz
Mercedes-Benz Description: M10X1
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1mm
Outside diameter: 21,8mm
Width across flats: 16mm. Shock absorber to bearing. Piston rod, left and right.
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1mm
Outside diameter: 21,8mm
Width across flats: 16mm. Shock absorber to bearing. Piston rod, left and right.
MSRP $11.00
$9.28
MSRP $11.00
$9.28
210
Nut Mercedes-Benz
Mercedes-Benz Description: Damper fastening left and right. M8
Diameter: 8mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut mounting top. Pressure reservoir bracket to body. Shock absorber,top.
Diameter: 8mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut mounting top. Pressure reservoir bracket to body. Shock absorber,top.
MSRP $4.40
$3.77
MSRP $4.40
$3.77
220
Leaf Spring Bolt Mercedes-Benz
Mercedes-Benz Description: Spring strut on wishbone. M16X1,5X120
Diameter: 16mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Spring link to frame-type int. Supp.. Shock absorber mount, lower left. Spring link to left rear axle carrier.
Diameter: 16mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Spring link to frame-type int. Supp.. Shock absorber mount, lower left. Spring link to left rear axle carrier.
MSRP $17.50
$15.23
MSRP $17.50
$15.23
230
Nut Mercedes-Benz
Mercedes-Benz Description: Suspension strut to spring linkDiameter: 16mmStrength / hardness class: 10Thread code letter: MThread pitch: 1,5mmOutside diameter: 34,5mmWidth across flats: 24mm. SHOCK ABSORBER TO LOWER CONTROL ARMDiameter: 16mmStrength / hardness class: 10Thread code le ...
MSRP $4.50
$3.92
MSRP $4.50
$3.92
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
