Cockpit Cable Harness for 2011 Mercedes-Benz GL550
No.
Part # / Description / Price
Price
100
Electrical Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cock pit wiring harness.
100
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cock pit wiring harness.
100
MSRP $575.00
$435.61
100
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cock pit wiring harness.
100
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cock pit wiring harness.
100
MSRP $448.00
$345.72
105
Fuse Box Mercedes-Benz
Mercedes-Benz Description: F 10-18 gsk. Cockpit f3. Instrument panel, #10-18. Ninefold f 10-18.
MSRP $21.00
$18.13
MSRP $21.00
$18.13
110
Cable Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX. 4.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
110
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX 0.35--1.0 MM2. 1.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
110
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
Description: REAR FUSE BOX 1,5-2,5 MM2. 1.5 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 1,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
115
Socket-Outlet Mercedes-Benz
Mercedes-Benz Description: Connector cockpit/frame floor system x18*1. 60-pin mqs. Cockpit/interior plug connector 60-pin, x18. 60-pin mqs.
115
Plug Mercedes-Benz
Mercedes-Benz Description: Connector, interior/engine black x25/2*2. 6-pin mcp2.8. Cockpit/interior plug connector x18. 6-pin mcp2.8. Connector, cockpit/interior, black x18. 6-pin mcp2.8. Engine compartment/interior connector x25/2. 6-pin mcp2.8.
MSRP $7.00
$5.95
MSRP $7.00
$5.95
120
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.39
MSRP $2.80
$2.39
120
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: 0.2-0.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 0,2-0,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 0,2-0,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.40
$2.90
MSRP $3.40
$2.90
120
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8.
MSRP $2.50
$2.18
MSRP $2.50
$2.18
120
Plug Pin Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.08-0.14 MM2 MQSLeitungsquerschnitt Min/Max: 0,08-0,14mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Gold. 0.08-0.14 MM2 MQSLeitungsquerschnitt Min/Max: 0,08-0,14mm2Oberflächensch ...
MSRP $6.00
$5.22
MSRP $6.00
$5.22
135
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Can b voltage distributor x30/4. 22-pin.
MSRP $4.50
$3.92
MSRP $4.50
$3.92
140
Distributor Mercedes-Benz
Mercedes-Benz Description: Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.
MSRP $37.00
$29.04
MSRP $37.00
$29.04
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Steering column electrically adjustable x4/39-m20/1+2. On steering column jacket tube.
300
310
Plug Mercedes-Benz
Mercedes-Benz Description: Rear-end window roller blind. 6 PIN SLK2.8Model 1: SLKModel 2: 2.8Slots: 6Release tool: W220 589 01 99 62. TANK CONNECTOR X25/4. 6 PIN SLK2.8Model 1: SLKModel 2: 2.8Slots: 6Release tool: W220 589 01 99 62. Rear window roller blind connector x19/3*1. 6 pin ...
MSRP $7.00
$5.95
MSRP $7.00
$5.95
315
Plug Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.5-0.75 MM2 SLK2.8. Front door connector to frame floor system. 0.5-0.75 mm2 slk2.8. Circuit 15r/58d connector x39/29. 0.5-0.75 mm2 slk2.8. Module box separation point x35/15. 0.5-0.75 mm2 slk2.8. Radio remote control separation point for central locking x35/71. 0.5-0.75 mm2 slk2.8. Silver. 0.5-0.75 mm2 slk2.8. 0,5-1,0mm. 0.5-0.75 mm2 slk2.8. To a 220 545 92 28. 0.5-0.75 mm2 slk2.8.
MSRP $4.00
$3.48
MSRP $4.00
$3.48
315
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 1.5-2.5 MM2 SLK2.8Leitun ...
MSRP $4.00
$3.48
MSRP $4.00
$3.48
350
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Left and right rear doors. Trim strip illumination, cockpit.
500
MSRP $29.50
$23.10
515
Contact Socket Mercedes-Benz
Mercedes-Benz Description: DOOR SEPARATION POINT, REAR X35/3,X35/4. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AuELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Copper. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: ...
MSRP $7.00
$5.95
MSRP $7.00
$5.95
520
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ALSO ORDER: TERMINAL BLOCK 2 X A 001 546 99 41; CABLE TIE 5 X A 002 997 24 90
MSRP $50.00
$39.60
MSRP $50.00
$39.60
