Control Modules and Relays in Load Compartment for 2011 Mercedes-Benz CLS63 AMG
No.
Part # / Description / Price
Price
5
Control Unit 1
Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Battery control module in trunk.
10
Securing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Top central partition panel to top left and right partition panels. Fastening battery control module. Guide plate to sliding roof plate. Sliding roof mechanism to sliding roof plate. Mounting, sensor.
15
MSRP $3.50
$3.05
30
MSRP $2.40
$2.03
100
Holder Mercedes-Benz
Mercedes-Benz Description: Fastening, control modules in trunk top left. Control unit fixture.
105
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Fastening, control modules in trunk lower left.
105
Holder Mercedes-Benz
Mercedes-Benz Description: Fastening, control modules in trunk lower left. Control unit hitching mechanism.
120
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
140
Elec Center, Base Module Mercedes-Benz
Mercedes-Benz Description: Signal acquisition and actuation module with rear fuse and relay module sam/srb.
140
Exchange Elec Center, Base Module 1 Mercedes-Benz
Mercedes-Benz Description: Signal acquisition and actuation module with rear fuse and relay module sam/srb n10/2.
140
Elec Center, Base Module Mercedes-Benz
Mercedes-Benz Description: Signal acquisition and actuation module with rear fuse and relay module.
140
Elec Center, Base Module Mercedes-Benz
Mercedes-Benz Description: Signal acquisition and actuation module with rear fuse and relay module.
150
Relay Mercedes-Benz
Mercedes-Benz Description: Changer. Plug position: g/h. Plug position: p. Cooling water pump k60. Tank cap pole reversal 1, slot:. Luggage compartment,right. Slot p. Remote trunk release. K41/1. Filler cap, inner.
150
Relay Mercedes-Benz
Mercedes-Benz Description: Rear, pos. C,f. Front. HEATED REAR WINDOW PANE RELAYModel 2: Schliesser / closing contactVolt: 12VAmps: 50A. PLUG POSITION: NModel 2: Schliesser / closing contactVolt: 12VAmps: 50A. RELAY SLOT 0, SECONDARY AIR PUMPModel 2: Schliesser / closing contactVolt: ...
150
Relay Mercedes-Benz
Mercedes-Benz Description: Slot K
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT J
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. PLUG POSITION C
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT D
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. Slot P
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A.
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT J
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. PLUG POSITION C
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. SLOT D
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A. Slot P
Model 2: Schliesser / closing contact
Volt: 12V
Amps: 20A.
MSRP $25.00
$21.75
MSRP $25.00
$21.75
160
MSRP $4.20
$3.63
160
Fuse Mercedes-Benz
Mercedes-Benz Description: Retainer. SAM control unit, front 10A. Radio or comand. Blade fuse ATO. Electrical center. Engine compartment, 10 amp. Rear, 10 amp. Instrument panel, 10 amp. Underhood, 10a.
MSRP $7.00
$6.09
MSRP $7.00
$6.09
160
Fuse Link Mercedes-Benz
Mercedes-Benz Description: Electrical center. 5a. Slot 9, parktronic. 5a.
MSRP $3.70
$3.22
MSRP $3.70
$3.22
160
Multi-Purpose Fuse Mercedes-Benz
Mercedes-Benz Description: Retainer. 30A. Fuel pump. 30a. SAM control unit, front 30A. 30A. Headlamp wiper/washer 30a. 30a.
MSRP $7.50
$6.38
MSRP $7.50
$6.38
205
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Upper air regulation system mount. M6x24.
MSRP $3.20
$2.76
MSRP $3.20
$2.76
205
Screw Mercedes-Benz
Mercedes-Benz Description: M6x18. Rear seat bench backrest to rear panel. Fender to body. Front fender to wheelhouse.
MSRP $2.40
$2.03
MSRP $2.40
$2.03
350
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Fuel pump unit, left. Fuel pump n118/3.
MSRP $461.50
$356.04
MSRP $461.50
$356.04
360
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Mounting, fuel system control unit and compensator.
360
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Mounting, fuel system control unit and compensator.
400
520
Grommet Mercedes-Benz
Mercedes-Benz Description: Cover to left seat cushionDiameter: 5mmOutside diameter: 18,6mm. AT FLOOR REAR CENTRAL 5 MMDiameter: 5mmOutside diameter: 18,6mm. RETAINING BELT FASTENINGDiameter: 5mmOutside diameter: 18,6mm. FELT FASTENING TO BRACKETDiameter: 5mmOutside diameter: 18,6mm. ...
MSRP $2.40
$2.03
MSRP $2.40
$2.03
700
MSRP $4.20
$3.63
700
Plug Mercedes-Benz
Mercedes-Benz Description: Connector: 4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Signal acquisition and actuation module with rear fuse and relay module. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Sam/srb control module rear black n10/2*4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1.
model 1: mcp
model 2: 2.8
slots: 1. Signal acquisition and actuation module with rear fuse and relay module. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1. Sam/srb control module rear black n10/2*4hd. 1-pin mcp2.8
model 1: mcp
model 2: 2.8
slots: 1.
700
MSRP $4.20
$3.63
710
Contact Socket Mercedes-Benz
Mercedes-Benz Description: Silver-plated. 4.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30. With single-wire seal. 4.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30. With single-wire seal. 4.0 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30.
MSRP $3.00
$2.61
MSRP $3.00
$2.61
710
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$6.09
MSRP $7.00
$6.09
740
Receptacle Mercedes-Benz
Mercedes-Benz Description: Sam/srb control module rear black n10/2. 5-pin slk2.8. Rear sam/srs-fp control module slot 20 n10/2, code a. 5-pin slk2.8.
750
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: With single-wire seal. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgModel 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62. SOUND AMPLIFIER N40/3,N93/1. 4.0 MM2 SLK2.8Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PIN ...
760
Plug Mercedes-Benz
Mercedes-Benz Description: Electronic ignition lock (ezs) control unit n73*2. 2-pin mcp2.8. Signal acquisition and actuation module with rear fuse and relay module. 2-pin mcp2.8. Front sam/srb control module, neutral n10/1,. 2-pin mcp2.8. Sam/srb control module rear neutral n10/2, code b. 2-pin mcp2.8. Fuse and relay module, driver n10/1 / 11. 2-pin mcp2.8.
760
Housing Mercedes-Benz
Mercedes-Benz Description: Dynamic seat pump A77. 5-PIN MQS, MCP2.8Model 1: MQS/MCPModel 2: 2.8Slots: 5Release tool: W220 589 01 99 60 / W000 589 13 99 30. Sam/srb control module rear neutral n10/2,. 5-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 5release tool: w220 589 01 99 6 ...
760
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Rear sam/srb control module, green n10/2. 5-pin mqs/mcp2.8. Fuse and relay module, rear n10/2 /23. 5-pin mqs/mcp2.8.
760
Plug Mercedes-Benz
Mercedes-Benz Description: 3rd stop lamp e21. 2-pin mqsmodel 1: mqsslots: 2. Signal acquisition + actuation module with front fuse and relay module n10/1. 2-pin mqsmodel 1: mqsslots: 2. Heated washer nozzle r2/8. 2-pin mqsmodel 1: mqsslots: 2. Control module sam/srb front, green n10 ...
MSRP $5.25
$4.50
MSRP $5.25
$4.50
760
Socket-Outlet Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, rear n10/2. 6-pin, cod.
MSRP $15.50
$13.49
MSRP $15.50
$13.49
770
Contact Socket Mercedes-Benz
Mercedes-Benz Description: STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
MSRP $5.75
$4.93
MSRP $5.75
$4.93
780
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Sam/srb control module rear violet n10/2,code d. 2-pin mcp2.8. Fuse and relay module, rear n10/2. 2-pin mcp2.8.
780
Housing Mercedes-Benz
Mercedes-Benz Description: Control module sam/srb rear n10/2. 7-pin mcp2.8. Tail lamp. 7-pin mcp2.8. Glove compartment lamp e13/2. 7-pin mcp2.8.
MSRP $4.90
$4.21
MSRP $4.90
$4.21
780
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Bus node (roof) n70. 5-pin mqs/mcp2.8. Front door control unit, black n69/1,n69/2,code a. 5-pin mqs/mcp2.8. Sam/srb control module rear black n10/2,code a. 5-pin mqs/mcp2.8.
780
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: "sam" control unit rear n10/2. 2-pin mcp2.8. Sam/srb control module, rear blue n10/2,2-pin,code c. 2-pin mcp2.8. Fuse and relay module, driver n10/1 /21. 2-pin mcp2.8.
780
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Sam/srb control module rear violet n10/2,code d. 4-pin mcp2.8. Fuse and relay box, rear n10/2. 4-pin mcp2.8.
780
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: "sam" control unit rear. 4-pin mcp 2.8. Control module sam/srb front, blue n10/1,. 4-pin mcp 2.8. Sam/srb control module, rear blue n10/2, code c. 4-pin mcp 2.8. Central locking system n10/2 13. 4-pin mcp 2.8. Fuse and relay module, driver n10/1/12. 4-pin mcp 2.8.
790
Contact Socket Mercedes-Benz
Mercedes-Benz Description: BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
MSRP $7.00
$5.95
MSRP $7.00
$5.95
