Frame Floor Unit Main Cable Harness for 2003 Mercedes-Benz SLK320
No.
Part # / Description / Price
Price
5
Electrical Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Tail lamp cable harness.
5
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Tail lamp cable harness.
5
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER F298214, ORDER PART NUMBER W/O ES1
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
Description: Tail lamp cable harness.
5
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER F298214, ORDER PART NUMBER W/O ES1
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
Description: Tail lamp cable harness.
10
Electric Line Mercedes-Benz
Mercedes-Benz Notes: STATE IDENT NO. WHEN ORDERING
Description: Belt locking retractor. Belt tensioner squib. Co-driver's air bag primer pellet.
MSRP $28.50
$22.44
MSRP $28.50
$22.44
10
Electric Line Mercedes-Benz
Mercedes-Benz Notes: STATE IDENT NO. WHEN ORDERING
Description: Side airbag repair solution. 2-pinmodel 1: rkmodel 2: 1slots: 2. Sidebag, left r12/9. 2-pinmodel 1: rkmodel 2: 1slots: 2. Front passenger airbag squib. 2-PINModel 1: RKModel 2: 1Slots: 2. Front passenger airbag, yellow. 2-pinmodel 1: rkmodel 2: 1slots: 2. ...
50
Plug Mercedes-Benz
Mercedes-Benz Description: Front door speaker h4/5, h4/6. 6-pin. Front door speaker h 4/3. 6-pin. Roller blind motor m 24. 6-pin. Loudspeaker. 6-pin. Right tail lamp. 6-pin. License plate lamp e19/1. E19/2. 6-pin.
55
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: ...
MSRP $8.00
$6.82
MSRP $8.00
$6.82
65
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
MSRP $2.90
$2.47
MSRP $2.90
$2.47
70
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Interior lamps. 2-pin. Belt locking retractor. 2-pin. Dome lamp,front. 2-pin. Unipolar. 2-pin. Economy drive switch. 4-pole. 2-pin. Trunk lid. 2-pin. Stop light switch 2 polig. 2-pin. Asd/asr. 2-pin. Thermo-switch heating washer system. 2-pin. Parking brake control. 2-pin.
75
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...
MSRP $2.70
$2.32
MSRP $2.70
$2.32
80
Plug Mercedes-Benz
Mercedes-Benz Description: Rpm sensor. 8-pin. To engine plug connection / cockpit control module me in module box. 8-pin. Diagnosis box plug connection 8-polig. 8-pin. Control unit box/engine sep. Point. 8-pin. Tail lamp cable harness plugconnection. 8-pin.
85
Contact Pin Mercedes-Benz
Mercedes-Benz Description: 207. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. RPM SENSOR 0,5-1,0mm2. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. 0,5-1,0 MM. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5.
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. RPM SENSOR 0,5-1,0mm2. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5. 0,5-1,0 MM. 0.5-1.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DIA
Model 2: 2.5.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
90
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Wiper motor. 4-pin spt. Pneumatic control unit. 4-pin spt. Airbag, passenger side. 4-pin spt. Door separation point,a-pillar. 4-pin spt. Electrical center. 4-pin spt. Relay. 4-pin spt.
MSRP $4.90
$4.21
MSRP $4.90
$4.21
95
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$4.21
MSRP $4.90
$4.21
100
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Operating unit. 18-pin mqs
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
model 1: mqs
slots: 18. Automatic air conditioner. 18-pin mqs
model 1: mqs
slots: 18. Central locking mechanism pump. 18-pin mqs
model 1: mqs
slots: 18. Control unit door. 18-pin mqs
model 1: mqs
slots: 18. Control unit pse. 18-pin mqs
model 1: mqs
slots: 18. Radio navigation control unit 18-polig. 18-pin mqs
model 1: mqs
slots: 18.
MSRP $4.50
$3.92
MSRP $4.50
$3.92
105
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$8.27
MSRP $9.50
$8.27
135
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0,5-1,0 MM2, TO 032 545 19 28. 0.5-1.0 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO A 029 545 19 28. 0.5-1.0 MM2 ...
MSRP $5.75
$4.93
MSRP $5.75
$4.93
135
Contact Socket Mercedes-Benz
Mercedes-Benz Description: TO A 029 545 19 28. 2.6-4.0 MM2 RK2.5
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: RK
Model 2: 2.5
Release tool: W220 589 01 99 30 / W220 589 01 99 53.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: RK
Model 2: 2.5
Release tool: W220 589 01 99 30 / W220 589 01 99 53.
160
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Folding top plug-connection. 2-pin. Adaptive damping system plugconnection. 2-pin. Door separation point,a-pillar. 2-pin.
170
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Door separation point,a-pillar. 2-pin. Heated rear window pane plug-connection. 2-pin. Automatic transmission plug-connection. 2-pin.
175
Contact Pin Mercedes-Benz
Mercedes-Benz Description: Partition point pri. Veh. Warn. Sig. X41/4. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: DIAModel 2: 2.5. DOOR SEPARATION POINT 1,0-2,5 MM2. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberfl ...
MSRP $1.70
$1.45
MSRP $1.70
$1.45
220
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Contact strip front pass. Side yel. Automatic child seat recognition. 4-pin mqs
model 1: mqs
slots: 4. Seat contacting. 4-pin mqs
model 1: mqs
slots: 4. Separation point, upfront sensor, driver x18/38. 4-pin mqs
model 1: mqs
slots: 4.
model 1: mqs
slots: 4. Seat contacting. 4-pin mqs
model 1: mqs
slots: 4. Separation point, upfront sensor, driver x18/38. 4-pin mqs
model 1: mqs
slots: 4.
MSRP $4.50
$3.92
MSRP $4.50
$3.92
230
Plug Mercedes-Benz
Mercedes-Benz Description: Pressure sensor, front door b48/7,b48/8. 3 pin. Tilting cone sensor. 3 pin. Control unit to side part b48/7, b48/8. 3 pin. Sensor side airbag left a53/1. 3 pin. Airbag pressure sensor b48/7,b48/8,b48/9,b48/10. 3 pin. Sensor sidebag a53, a54. 3 pin. Sensor side airbag right a54. 3 pin.
MSRP $3.00
$2.61
MSRP $3.00
$2.61
235
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITHOUT SEAL. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85. GOLD. 0.5 MM2 MQS
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Au
Model 1: MQS
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.00
$7.83
MSRP $9.00
$7.83
240
Receptacle Mercedes-Benz
Mercedes-Benz Description: Door contact switch s17/1. S17/2. 3-pin. Door contact, b-pillar, left s17/3. 3-pin. Roof rack plug-in connection. 3-pin. Connector cockpit roof x18/23. 3-pin. Left front door connector x34/1. 3-pin. Left rear door contact switch S17/3,S17/4. 3-PIN. Door contact switch,left and right s17/3 / s17/4. 3-pin.
245
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
MSRP $11.50
$9.85
MSRP $11.50
$9.85
257
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4,0 MM. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52. TO 008 545 08 28,000 821 22 26. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52.
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52. TO 008 545 08 28,000 821 22 26. 0.35-6.0 MM2 RK4.0
Leitungsquerschnitt Min/Max: 0,35-6,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: RK
Model 2: 4.0
Release tool: W220 589 01 99 52.
MSRP $3.40
$2.90
MSRP $3.40
$2.90
265
Receptacle Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: FFModel 2: 6.3. TO 001 545 10 28,012 545 31 28. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: ...
MSRP $2.70
$2.32
MSRP $2.70
$2.32
270
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Windshield washer/dome-lamp switch. 6-pin. Folding top actuation switch. 6-pin.
280
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Mirror adjustment switch. 8-pole. 8-pin. Rearview mirror glare control switch. 8-pin. Autside rearview mirror adjustment switch. 8-pin.
310
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Transmission control module n15/3. 12-pin jptmodel 1: jptmodel 2: 2.8slots: 12release tool: w000 589 13 99 30. Electronic transmission control n15/3. 12-pin jptmodel 1: jptmodel 2: 2.8slots: 12release tool: w000 589 13 99 30. Air brake and central locking ...
MSRP $4.90
$4.26
MSRP $4.90
$4.26
310
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Electronic transmission control (etc) control unit. Contact bridge with diode,bipolar. Used with window regulator.
315
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0,5-1,0 MM2. 0.5-1.0 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 1: JPT
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: +
Model 1: JPT
Model 2: 2.8.
320
Socket-Outlet Mercedes-Benz
Mercedes-Benz Description: Electronic transmission control (etc) control unit. Control unit egs.
320
Cap Mercedes-Benz
Mercedes-Benz Description: N15/3. Electronic transmission control (etc) control unit. 18-pin jpt.
330
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Air bag cable harness plug-connection. 2-pin. Door separation point,b-pillar. 2-pin. Intermediate connector, airbag. 2-pin. Primer pellet. 2-pin. Plug connection contact spiral airbag. 2-pin. Seat contacting. 2-pin.
350
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Plug connection 4 polig, (motorraum/cockpit). 4-pin. Tail lamp cable harness plugconnection. 4-pin. Engine plug connection cockpit. 4-pin.
360
Plug Mercedes-Benz
Mercedes-Benz Description: Warning device. 3-pin. Connector ata front / ata rear. 3-pin. Plug connection anti-theft alarm system front and rear. 3-pin. Plug connection radio/sound system. 3-pin.
370
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Left ventilator window. 6-pin. Roller blind switch. 6-pin. Switch esp-off. 6-pin. Switch, rear window blind. 6-pin. Switch "asr". 6-pin.
375
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0,35MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Release tool: W220 589 01 99 55. 0,5-1,0 MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Relea ...
MSRP $5.00
$4.34
MSRP $5.00
$4.34
380
Plug Mercedes-Benz
Mercedes-Benz Description: Ignition lock. 8-pin+2-pin. Selector lever module. 8-pin+2-pin. Gear recognition switch. 8-pin+2-pin.
415
MSRP $3.70
$3.22
425
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$6.09
MSRP $7.00
$6.09
450
Plug Mercedes-Benz
Mercedes-Benz Description: Left 02 probe upstream of cat. G3/3. Oxygen sensor,black. Oxygen sensor downstream of catalytic converter g3/5. 02 sensor in front of catalytic converter 4-pin. Diagnosis probe. Oxygen sensor plug connection. Fuel delivery pump control unit n118.
MSRP $10.00
$8.56
MSRP $10.00
$8.56
465
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: With seal. 1.0 MM2 LKS 1.5
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: LKS
Model 2: 1.5. Fuel delivery pump control unit n118. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5. Oxygen sensor downstream of catalytic converter g3/5. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5.
Leitungsquerschnitt Min/Max: 1,0mm2
Model 1: LKS
Model 2: 1.5. Fuel delivery pump control unit n118. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5. Oxygen sensor downstream of catalytic converter g3/5. 1.0 mm2 lks 1.5
leitungsquerschnitt min/max: 1,0mm2
model 1: lks
model 2: 1.5.
MSRP $7.50
$6.53
MSRP $7.50
$6.53
470
Contact Socket Housing Mercedes-Benz
Mercedes-Benz Description: Transmission control. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Control unit. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. (valve unit) "nag". 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Etc valve unit. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Valve strip. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Automatic transmission. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12.
model 1: lks
model 2: 1.5
slots: 12. Control unit. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. (valve unit) "nag". 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Etc valve unit. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Valve strip. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12. Automatic transmission. 12-pin lks1.5
model 1: lks
model 2: 1.5
slots: 12.
MSRP $16.00
$13.92
MSRP $16.00
$13.92
475
Cap Mercedes-Benz
Mercedes-Benz Description: Electronic control. To 001 540 99 81. Control unit. (valve unit) "nag".
MSRP $4.00
$3.48
MSRP $4.00
$3.48
480
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0.75-1.0 MM2 LKS 1.5
Leitungsquerschnitt Min/Max: 0,75-1,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LKS
Model 2: 1.5.
Leitungsquerschnitt Min/Max: 0,75-1,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LKS
Model 2: 1.5.
MSRP $3.90
$3.34
MSRP $3.90
$3.34
510
Housing Mercedes-Benz
Mercedes-Benz Description: Roof sign connecting point, black x41/2. 18-pin mqs. Connector, interior and subharness for taillamp x18. 18-pin mqs. Engine residual heat utilization. 18-pin mqs. Separation point vda, x14/12. 18-pin mqs.
MSRP $7.25
$6.24
MSRP $7.25
$6.24
520
Plug Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Engine/body/etc connector. 4-pin. Cockpit cable harness plug-connection. 4-pin.
530
Plug Mercedes-Benz
Mercedes-Benz Description: Door separation point,b-pillar. 8-pin. Plug connection for tail lamp wiring harness,eight-pin. 8-pin. Oxygen sensor separation point. 8-pin. To engine plug connection / cockpit control module me in module box. 8-pin. Engine cable harness plug-connection to frame mounted cable harness. 8-pin. Plug connection,speed sender unit. 8-pin.
580
Clutch Housing Mercedes-Benz
Mercedes-Benz Description: Sam/srb control module rear black n10/2,. 5-pin jpt. Dome lamp, delay. 5-pin jpt.
580
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Dome lamp, delay. 5-pin jpt. Airbag, passenger side. 5-pin jpt. Tail lamp. 5-pin jpt. Control unit, steering lock. 5-pin jpt. Electric steering lock. 5-pin jpt.
MSRP $3.40
$2.90
MSRP $3.40
$2.90
585
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$3.05
MSRP $3.50
$3.05
590
Plug Mercedes-Benz
Mercedes-Benz Description: Stop lamp switch, neutral cod. B. 3-pin jpt. Loudspeaker. 3-pin jpt. Wiper motor. 3-pin jpt. Subwoofer speaker h4/29. 3-pin jpt.
600
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Stop lamp switch, black cod. A. 3-pin jpt. Radio set-antenna. 3-pin jpt. Fuse and relay box,driver 3 polig. 3-pin jpt. Antenna amplifier. 3-pin jpt. Central locking connector x35/71. 3-pin jpt. Fuse and relay box near driver's seat. 3-pin jpt. Stop light switch s9/1. 3-pin jpt. Driver's airbag. 3-pin jpt.
MSRP $5.50
$4.79
MSRP $5.50
$4.79
610
Plug Mercedes-Benz
Mercedes-Benz Description: Instrument cluster "i". 6-pin mqs. Instrument cluster "l". 6-pin mqs.
620
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Instrument cluster "c". 2-pin mqs. Sam control unit. 2-pin mqs.
630
640
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Subwoofer h4/38. 4-pin rk2.5. Plug connection for tail lamp wiring harness,four-pin. 4-pin rk2.5. Engine/body/etc connector. 4-pin rk2.5. Inboard cable harness plug-connection. 4-pin rk2.5. Frame plug-connection. 4-pin rk2.5. Diagnosis box. 4-pin rk2.5. Door separation point a-pillar,4-pole. 4-pin rk2.5. Sensor, level control. 4-pin rk2.5.
710
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Electrical center. 63-pin.
MSRP $47.00
$36.96
MSRP $47.00
$36.96
715
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER F298214, ORDER PART NUMBER W/O ES1
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
Description: HEATER BOOSTER SWITCH 0.5 - 1.0mm2. 0.75 MM2 E95 SN
Leitungsquerschnitt Min/Max: 0,75mm2
Oberflächenschutz PINs: Sn
Model 1: E95.
Leitungsquerschnitt Min/Max: 0,75mm2
Oberflächenschutz PINs: Sn
Model 1: E95.
MSRP $5.50
$4.64
MSRP $5.50
$4.64
720
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Control unit multi-contour backrest f1/7. Mpt 2.5 - 4.0 mm2. Fuse and relay module, driver k40/2.
725
Contact Spring Mercedes-Benz
Mercedes-Benz Description: MPT EINZELWARE 4.0 - 6.0 MM2
Leitungsquerschnitt Min/Max: 4,0-6,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MPT.
Leitungsquerschnitt Min/Max: 4,0-6,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MPT.
MSRP $5.25
$4.50
MSRP $5.25
$4.50
730
740
Cable Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX. 4.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
740
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================
Description: REAR FUSE BOX 1,5-2,5 MM2. 1.5 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 1,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
740
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX 0.35--1.0 MM2. 1.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
750
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 2.5 MM2 GSK3
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 3.
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 3.
MSRP $11.00
$9.28
MSRP $11.00
$9.28
750
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 6.0 MM2 GSK3
Leitungsquerschnitt Min/Max: 6,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 3.
Leitungsquerschnitt Min/Max: 6,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 3.
MSRP $18.50
$15.95
MSRP $18.50
$15.95
760
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX 1.5-2.5mm2. 2.5 MM2
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: -
Model 1: GSK.
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: -
Model 1: GSK.
MSRP $5.50
$4.79
MSRP $5.50
$4.79
760
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: 6.0 MM2
Leitungsquerschnitt Min/Max: 6mm2
Oberflächenschutz PINs: -
Model 1: GSK.
Leitungsquerschnitt Min/Max: 6mm2
Oberflächenschutz PINs: -
Model 1: GSK.
MSRP $22.50
$19.58
MSRP $22.50
$19.58
