Parktronic System (Pts) for 2003 Mercedes-Benz E500
No.
Part # / Description / Price
Price
10
20
Plug Housing
Mercedes-Benz
Mercedes-Benz Description: Pts output stage n62. To a 210 545 01 40. Pts output stage n 62. To 210 545 13 28. To a2105450140.
20
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Control module easy-shift manual tran. Control unit connection. 2-pin jpt
model 1: jpt
model 2: 2.8
slots: 2
release tool: w000 589 13 99 30.
model 1: jpt
model 2: 2.8
slots: 2
release tool: w000 589 13 99 30.
MSRP $6.25
$5.37
MSRP $6.25
$5.37
20
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Control module for electronic transmission control n15/6. To a 210 545 03 40. To 210 545 00 40. Relay.
20
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Transmission control module n15/3. 12-pin jptmodel 1: jptmodel 2: 2.8slots: 12release tool: w000 589 13 99 30. Electronic transmission control n15/3. 12-pin jptmodel 1: jptmodel 2: 2.8slots: 12release tool: w000 589 13 99 30. Air brake and central locking ...
MSRP $4.90
$4.26
MSRP $4.90
$4.26
30
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$3.05
MSRP $3.50
$3.05
90
Warning Device Mercedes-Benz
Mercedes-Benz Description: Below instrument panel,central. Parktronic system. Cockpit. Front.
MSRP $119.00
$91.59
MSRP $119.00
$91.59
105
MSRP $3.70
$3.19
150
Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Pts warning element connector (ffs) to cockpit warning element.
150
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Pts warning element connector (ffs) to cockpit warning element.
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$8.27
MSRP $9.50
$8.27
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Parktronic system. Parktronic sep. Point front wheelhouse to rear sam/srb control module.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
Description: Parktronic system. Parktronic sep. Point front wheelhouse to rear sam/srb control module.
300
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Parktronic system. Parktronic sep. Point front wheelhouse to rear sam/srb control module.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Parktronic system. Parktronic sep. Point front wheelhouse to rear sam/srb control module.
315
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.39
MSRP $2.80
$2.39
340
Plug Mercedes-Benz
Mercedes-Benz Description: Parking assist connector rear bumper x35/28. 8-pin mlk1.2. Parking assist connector, front bumper x26/27. 8-pin mlk1.2. Connector, front bumper frame floor assembly x 26/27. 8-pin mlk1.2. Actuator motor M70. 8-PIN MLK1.2. Additive reservoir x206. 8-pin mlk1.2. Connector, frame floor assembly and front bumper x26/38. 8-pin mlk1.2. Bumper connector x26/x27. 8-pin mlk1.2. Connector, parktronic, front bumper. 8-pin mlk1.2.
MSRP $6.00
$5.22
MSRP $6.00
$5.22
340
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Parktronic system. 8-pin rk1.0. Connector, parktronic, front bumper x26/27. 8-pin rk1.0. Repair solution x26/27. 8-pin rk1.0. Connector, front bumper frame floor assembly. 8-pin rk1.0.
345
Round Receptacle Mercedes-Benz
Mercedes-Benz Description: 1MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. 1,0 MM. 0.35-0.75 MM2 RK1.0Leitungsquerschnitt Min/Max: 0,35-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: RKModel 2: 1.0. DATA LI ...
MSRP $8.25
$7.11
MSRP $8.25
$7.11
345
Contact Socket Mercedes-Benz
Mercedes-Benz Description: A80. 0.22-0.5 MM2 MLK1.2Leitungsquerschnitt Min/Max: 0,22-0,5mm2Oberflächenschutz PINs: AgELA: +Model 1: MLKModel 2: 1.2Release tool: W220 589 01 99 25Crimp tool: W220 589 01 99 84. 02 SENSOR UPSTREAM OF CATALYTIC CONVERTER G3/3,G3/4. 0.22-0.5 MM2 MLK1.2L ...
MSRP $3.50
$3.05
MSRP $3.50
$3.05
345
Seal Mercedes-Benz
Mercedes-Benz Description: Induction throttle valve abs susp. Y86/1. 4.0 MM MLK1.2/LKS1.5Leitungsquerschnitt Min/Max: 4,0mm2ELA: +Model 1: MLK1.2/LKSModel 2: 1.5Release tool: W220 589 01 99 25Crimp tool: W220 589 01 99 84. FRONT VALVE UNIT Y36/1. 4.0 MM MLK1.2/LKS1.5Leitungsquerschn ...
MSRP $1.10
$0.90
MSRP $1.10
$0.90
350
