Rear Springs and Suspension Standard Suspension for 2003 Mercedes-Benz CLK 430

5

Rear Spring

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Color marking: 3 x gray. As required.

View Details

5

Rear Spring

202-324-21-04

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: As required. Color marking: 1 x blue / 2 x gray.

MSRP $85.00

$65.79

MSRP $85.00

$65.79

5

Rear Spring

2083240404

Mercedes-Benz

Notes: NO LONGER AVAILABLE
UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL

Description: Color marking: 2 x blue/ 1 x yellow.

View Details

5

Rear Spring

210-324-36-04

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL

Description: Color marking: 2 x yellow.

MSRP $112.00

$86.43

MSRP $112.00

$86.43

5

Helical Spring

202-324-18-04-64

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Color marking: 2 x gray. As required.

MSRP $99.00

$76.11

MSRP $99.00

$76.11

5

Rear Spring

202-324-20-04

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: As required. Color marking: 1 x blue / 1 x gray.

MSRP $82.00

$64.68

MSRP $82.00

$64.68

5

Rear Spring

202-324-17-04

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Color marking: 1 x gray. As required.

View Details

5

Rear Spring

208-324-00-04-64

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Color marking: 2 x red.

MSRP $74.00

$58.08

MSRP $74.00

$58.08

5

Rear Spring

210-324-34-04

Mercedes-Benz

Notes: UPON EXCHANGING SPRING, ALWAYS REPLACE LOWER SPRING SEAL

Description: Color marking: 3 x blue. As required.

MSRP $99.00

$76.11

MSRP $99.00

$76.11

8

Spring Retainer Insert

210-325-01-84

Mercedes-Benz

Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Upper. stud quantity: 1 (5mm). Top. Stud count: 1 (5mm). As required. Number of burls: 1 (5 mm).

MSRP $6.00

$5.22

MSRP $6.00

$5.22

8

Rubber Boot

2103250384

Mercedes-Benz

Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Upper. stud quantity: 3 (13mm). Top. Stud count: 3 (13mm). As required. Number of burls: 3 (13 mm).

MSRP $8.75

$7.54

MSRP $8.75

$7.54

8

Rubber Boot

2103250284

Mercedes-Benz

Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Upper. stud quantity: 2 (9mm). Top. Stud count: 2 (9mm). As required. Number of burls: 2 (9 mm).

MSRP $6.50

$5.66

MSRP $6.50

$5.66

8

Rubber Boot

2103250484

Mercedes-Benz

Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 208.335 25 550 HITCHING MECHANISM 7 208.344 29 412,414 SLIDINGROOF 3 208.345 28 211 AUTU. LIMITED-SLIP DIFFERENTIAL 3 208.347 33 673 HIGH CAPACITY BATTERY 3 208.348 36 248 INTEGRA TED CHILD'S SEAT 2 208.365 38 420,423 AUTOMATIC TRANSMISSION 1 208.370 45 955 ELEGANCE 1 208.374 55 480 SELF-LEVELLING DEVICE 1 510,511,518,516,512,251,253,254,255,750,752,753,754,755,756 RADIO 1 221,222,241,242,275 ELECTICALLY ADJUSTED FRONT SAET 1 540 ROLLERBLIND 1 819 CD CHANGER 1 810 SOUND-SYSTEM 1 274,314,316,317,319,347,852,853,854,855 TELEPHNE 1 625 FOR AUSTRALIA 4 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -35 208 324 00 04 210 325 01 84 36-42 208 324 00 04 210 325 02 84 43-48 208 324 00 04 210 325 03 84 49-55 208 324 00 04 210 325 04 84 . 56-61 202 324 17 04 210 325 01 84 62-68 202 324 17 04 210 325 02 84 69-74 202 324 17 04 210 325 03 84 75-81 202 324 17 04 210 325 04 84 . 82-87 202 324 18 04 210 325 01 84 88-94 202 324 18 04 210 325 02 84 95-100 202 324 18 04 210 325 03 84 101- 202 324 18 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS H.D. SPRING CODE 482 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -29 202 324 20 04 210 325 04 84 . 30-32 202 324 21 04 210 325 01 84 33-38 202 324 21 04 210 325 02 84 39-44 202 324 21 04 210 325 03 84 45-50 202 324 21 04 210 325 04 84 . 51-60 202 324 19 04 210 325 01 84 61-67 202 324 19 04 210 325 02 84 68-74 202 324 19 04 210 325 03 84 75- 202 324 19 04 210 325 04 84 . ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF LEVELLING DEVICE CODE 480 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD -33 202 324 28 04 210 325 01 84 34-38 202 324 28 04 210 325 02 84 39-43 202 324 28 04 210 325 03 84 . 44-48 202 324 31 04 210 325 01 84 49-53 202 324 31 04 210 325 02 84 54-58 202 324 31 04 210 325 03 84 59- 202 324 31 04 210 325 04 84 . ==============================================================================================================================

Description: Top. Stud count: 4 (17mm). As required. Number of burls: 4 (17 mm). Upper. stud quantity: 4 ( 17MM).

MSRP $8.75

$7.61

MSRP $8.75

$7.61

9

Spring Shim

203-324-00-84

Mercedes-Benz

Description: Rear spring, bottom.

MSRP $15.00

$13.05

MSRP $15.00

$13.05

11

Shock Absorber

208-326-08-00

Mercedes-Benz

Notes: ONLY REPLACEABLE BY PAIRS

View Details

11

Shock Absorber

208-326-04-00

Mercedes-Benz

View Details

11

Shock

208-326-05-00

Mercedes-Benz

Notes: FASTENING PARTS NOT PART OF DELIVERY SPEC., PLEASE ORDER SEPARATELY
ONLY REPLACEABLE BY PAIRS

MSRP $264.00

$203.82

MSRP $264.00

$203.82

14

Hexagon Head Bolt

910105010003

Mercedes-Benz

MSRP $10.50

$8.99

MSRP $10.50

$8.99

17

Washer

000000-003386

Mercedes-Benz

Description: Refrigerant compressor to support. Bearing cup to bearing bracket.

MSRP $2.70

$2.32

MSRP $2.70

$2.32

20

Hexagon Nut

910113010003

Mercedes-Benz

Description: M10
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Propeller shaft to transmission. Shock absorber to lower control arm m 10x1. Shock absorber to spring control arm m 10x1. Hydropneumatic spring leg to spring control arm m 10. Shock absorber to frame. Hydropneumatic spring leg to rear axle.

MSRP $4.40

$3.77

MSRP $4.40

$3.77

23

Rubber Bumper

2023260468

Mercedes-Benz

Description: Bumper to body. Shock absorber to frame.

MSRP $5.75

$4.93

MSRP $5.75

$4.93

26

Rubber Bumper

2023260168

Mercedes-Benz

Description: Bumper to body. Shock absorber to frame. Hydropneumatic spring leg to frame.

MSRP $4.70

$4.06

MSRP $4.70

$4.06

29

Window

2023260076

Mercedes-Benz

Description: Shock absorber to frame. Bumper to body. Hydropneumatic spring leg to frame. Shock absorber to rear axle.

MSRP $3.70

$3.19

MSRP $3.70

$3.19

32

Hexagon Nut

308673-010001-64

Mercedes-Benz

Description: M10X1
Diameter: 10mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Front shock absorbers to frame. Bumper to body. Shock absorber to frame m 10x1. Hydropneumatic spring leg to frame m 10x1.

MSRP $3.70

$3.19

MSRP $3.70

$3.19

35

Fastening Parts

210-990-03-99

Mercedes-Benz

Description: Shock absorber mounting,front. Shock absorber mounting,rear. Hydropneumatic spring leg mounting.

MSRP $28.50

$22.44

MSRP $28.50

$22.44
