Refrigerant Line Arrangement for 2002 Mercedes-Benz S55 AMG
No.
Part # / Description / Price
Price
10
10
MSRP $202.00
$156.09
20
A/C Line O-Ring
Mercedes-Benz
Mercedes-Benz Description: All Required. 9.5 x 2.5mm. Auxiliary A/C.
MSRP $4.70
$4.06
MSRP $4.70
$4.06
20
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
30
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
MSRP $14.50
$12.57
MSRP $14.50
$12.57
50
Valve Mercedes-Benz
Mercedes-Benz Description: Test connection. De-aeration valve. Filling valve. In suction line.
MSRP $29.50
$23.10
MSRP $29.50
$23.10
70
Clamping Piece Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Suction line to shock-absorber strut. Tubing of expansion valve to separation point.
80
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M6. Bracket to water tank. Mounting parts. Control unit. Bracket mounting. Brake booster assembly to asr bracket. Fuel lines to cowl. Transistorized ignition switchgear to wheelhouse panel. Roller blind to rear panel covering, top.
MSRP $3.40
$2.90
MSRP $3.40
$2.90
90
MSRP $3.00
$2.61
105
O-Ring Mercedes-Benz
Mercedes-Benz Description: Separation point. 23.8x2.4. Suction line to expansion valve. 23.8x2.4. Suction line to compressor. 23.8x2.4.
MSRP $1.90
$1.60
MSRP $1.90
$1.60
110
Piping Mercedes-Benz
Mercedes-Benz Description: Fluid-reservoir-to-expansion-valve refrigerant line.
MSRP $182.00
$140.61
MSRP $182.00
$140.61
115
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
MSRP $3.70
$3.19
MSRP $3.70
$3.19
130
O-Ring Mercedes-Benz
Mercedes-Benz Description: Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
MSRP $3.20
$2.73
MSRP $3.20
$2.73
132
Discharge Line Valve Mercedes-Benz
Mercedes-Benz Description: Condenser. To 140 830 05 70. To 129 830 02 70,129 830 04 70. Filling valve. In pressure line.
MSRP $22.50
$19.56
MSRP $22.50
$19.56
135
Clamping Piece Mercedes-Benz
Mercedes-Benz Description: Line mounting. 5 mm. Line aux.heater left rear seat floor. 5 mm. Damper strut delivery line. 5 mm. Pressure line to shock-absorber strut. 5 mm. Front brake cable to tunnel. 5 mm. Pipe line to wheelhouse. 5 mm. Rear floor assembly right. 5 mm. To right rear wheelhouse. 5 mm.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
140
Pressure Line Mercedes-Benz
Mercedes-Benz Description: From compressor to condenser. Compressor-to-condenser refrigerant line.
MSRP $250.00
$192.21
MSRP $250.00
$192.21
190
MSRP $12.00
$10.15
210
MSRP $199.00
$153.51
220
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Pressure switch to liquid tank used for additional blower. 9.0 x 1.8 mm. Pressure switch to liquid tank used for compressor. 9.0 x 1.8 mm. At liquid tank. 9.0 x 1.8 mm. Refrigerant reservoir valve. 9.0 X 1.8 MM. Sensor. 9.0 x 1.8 mm.
230
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: At liquid tank,for additional blower. Outdoor temperature sensor.
270
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.39
MSRP $2.80
$2.39
280
Snap Fastener Mercedes-Benz
Mercedes-Benz Description: Mounting pipe line. Suction line to shock-absorber strut. Climate line attachment. Piping mount. At solenoid valve. Mounting solenoid valve.
290
Grommet Mercedes-Benz
Mercedes-Benz Description: Suction line to bracket. At solenoid valve. Mounting solenoid valve. Solenoid valve to crossmember. At bracket on shock absorber console.
330
MSRP $3.40
$2.90
360
