Antenna, Antenna Amplifier and Wiringharnesses for 2002 Mercedes-Benz CLK 55 AMG®
No.
Part # / Description / Price
Price
80
Radio Accessories
Mercedes-Benz
Mercedes-Benz Description: Ctel system preparation. Rear right. Clipped onto communication platform.
MSRP $87.00
$67.08
MSRP $87.00
$67.08
110
Logmatic GPS Splitter Mercedes-Benz
Mercedes-Benz Description: Front. Comand. Gps (global positioning system) connected to communications platform. Tele aid. Telephone. Ctel with emergency call system preinstallation.
190
Antenna Splitter Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Comand japan. Antenna selector, rear left. Luggage compartment,left.
240
Antenna Mercedes-Benz
Mercedes-Benz Description: Rear floor assembly right. To right vent flap. On ventilation flap right inside.
MSRP $182.00
$140.61
MSRP $182.00
$140.61
250
Screening Plate Mercedes-Benz
Mercedes-Benz Description: On ventilation flap left inside. For antenna on vent flap in luggage compartment, back.
300
Antenna Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Trunk lid, center. Car phone in trunk lid.
300
Antenna Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Trunk lid, left. Gps in trunk lid. Gps (global positioning system).
300
320
Edge Guard Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: To left rear longitudinal member. Left seat. Seat adjuster. Left wheel arch 163mm. Rear seat bench. 50 mm covering to rear body panel, bottom. 80 mm. Engine hood,28 mm. High roof. Jack fixture 163 mm.
MSRP $15.50
$13.49
MSRP $15.50
$13.49
400
400
400
400
400
400
450
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$8.27
MSRP $9.50
$8.27
455
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Power supply/antenna radio/comand.
455
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Power supply/antenna radio/comand.
470
Plug Mercedes-Benz
Mercedes-Benz Description: Plug distributor radio mute x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. Radio "mute" plug connection x30/12. 2-pinmodel 1: slkmodel 2: 2.8slots: 2. ...
MSRP $5.00
$4.35
MSRP $5.00
$4.35
490
Plug Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.5-0.75 MM2 SLK2.8. Front door connector to frame floor system. 0.5-0.75 mm2 slk2.8. Circuit 15r/58d connector x39/29. 0.5-0.75 mm2 slk2.8. Module box separation point x35/15. 0.5-0.75 mm2 slk2.8. Radio remote control separation point for central locking x35/71. 0.5-0.75 mm2 slk2.8. Silver. 0.5-0.75 mm2 slk2.8. 0,5-1,0mm. 0.5-0.75 mm2 slk2.8. To a 220 545 92 28. 0.5-0.75 mm2 slk2.8.
MSRP $4.00
$3.48
MSRP $4.00
$3.48
490
Plug Mercedes-Benz
Mercedes-Benz Description: Module box separation point x35/15. 3-pin. Radio remote control separation point for central locking x35/71. 3-pin. Separation point trunk lid 14-pin x8/4. 3-pin. Control unit box/engine sep. Point x35/63. 3-pin.
MSRP $4.40
$3.77
MSRP $4.40
$3.77
610
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Rear backrest. Connector to antenna.
700
700
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Antenna amplifier to operating unit.
800
899
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$6.09
MSRP $7.00
$6.09
