Rear Single Seats for 2000 Mercedes-Benz S430
No.
Part # / Description / Price
Price
30
40
Outer Cover
Mercedes-Benz
Mercedes-Benz Description: Leather nappa with ventilation, right. Nappa leather or exclusive leather, climate control, right.
40
50
Bracket Mercedes-Benz
Mercedes-Benz Description: Longitudinal upholstery, left seat. Staple upholstery seat cushion, long. Longitudinal staple upholstery, out. Left/right, right seat.
70
Bracket Mercedes-Benz
Mercedes-Benz Description: Upholstery cross stapling, rear. 240mm. Transversal tacking. 240mm. Cover stitching. 240mm. Cross stapling, cover, right. 240mm.
70
Bracket Mercedes-Benz
Mercedes-Benz Description: Center floor staple. 185 mm. Cross stapling, bottom. 185 mm. Cross staple upholstery, rear left seat. 185 mm. Lateral staple of cover, left seat for isofix. 185 mm. Inner side bolster. 185 MM. Left seat bolster. 185 MM. Cover stitching. 185 mm.
100
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear-seat backrest at body. M8X16
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Rear seat cushions mounting. Electric seat adjuster,left seat. Clutch pressure plate to flywheel. Rear cushion fastening, left.
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Rear seat cushions mounting. Electric seat adjuster,left seat. Clutch pressure plate to flywheel. Rear cushion fastening, left.
MSRP $3.40
$2.90
MSRP $3.40
$2.90
110
MSRP $4.40
$3.77
130
150
Insert Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Multicontour backrest, side left, left seat.
170
T-Type Distr Fitting Mercedes-Benz
Mercedes-Benz Description: Driver's seat. Left multi-contour backrest. Left seat. Right multi-contour backrest.
180
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: To backrest frame for clim.-cont. To backrest frame, left. Convenience seat, left. Air conditioning, driver seat left. Air conditioning, driver seat right. Seat ventilation.
MSRP $338.00
$260.58
MSRP $338.00
$260.58
190
Screw Mercedes-Benz
Mercedes-Benz Description: Fastening control moudle, left. Valve to steering lock. Backrest release m4x8.
200
200
Lining Mercedes-Benz
Mercedes-Benz Description: Nappa leather or exclusive leather, left, with rear seat climate control.
200
220
Clamp Mercedes-Benz
Mercedes-Benz Description: Seat cover mount. Cover stitching. Lining. Longitudinal stapling. Left. Fastening, bracket to seat cover.
250
290
Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Air/water duct to cross member. 4,8x16. Covering to engine hood. 4,8x16.
MSRP $2.90
$2.47
MSRP $2.90
$2.47
340
340
Valve Block Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Behind storage box under rear armrest.
350
MSRP $1.50
$1.31
