Rear Springs and Suspension Used with Self-Levelling Device for 1993 Mercedes-Benz 300SL
No.
Part # / Description / Price
Price
5
Rear Spring
Mercedes-Benz
Mercedes-Benz Notes: ONLY REPLACEABLE BY PAIRS
EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F 072943
EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. F 072943
5
Rear Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
129.058 28 211 AUTO. LIMITED-SLIP DIFFERENTIAL 2
129.060 18 223 REAR SEAT BENCH 2
129.061 35 810 SOUND SYSTEM 2
129.063 33 425 AUTOMATIC FIVE-SPEED TRANSMISSION 2
129.066 39 214, 216 SELF-LEVELLING DEVICE 2
129.067 39 420 AUTOMATIC FOUR-SPEED TRANSMISSION 1
129.076 45 228 ADDITIONAL HEATER 1
.
==============================================================================================================================
TABLE REAR SPRING - RUBBER BOOT NORMAL SPRINGS
==============================================================================================================================
SUM OF POINTS REAR SPRING BOOT: BOOT:
WITH BLUE REAR SPRING W/ RED REAR SPRING
-28 129 324 14 04 201 325 09 44 201 325 10 44
29-40 129 324 14 04 201 325 10 44 201 325 11 44
41-44 129 324 14 04 201 325 11 44
.
45 129 324 05 04 201 325 09 44
46-52 129 324 05 04 201 325 09 44 201 325 10 44
53-60 129 324 05 04 201 325 10 44 201 321 11 44
61- 129 324 05 04 201 325 11 44 .
==============================================================================================================================
CHART OF REAR SPRING RUBBER PADS W/SELF-LEVELLING DEVICE CODE 214, 216
==============================================================================================================================
TOTAL OF POINTS REAR SPRING PAD PAD
REAR SPRING BLUE REAR SPRING RED
-40 129 324 15 04 201 325 09 44 201 325 10 44
41-46 129 324 15 04 201 325 10 44 201 325 11 44
.
47-52 129 324 12 04 201 325 09 44 201 325 10 44
53- 129 324 12 04 201 325 10 44 201 325 11 44
.
==============================================================================================================================
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 129.066 AUS 38 329 AUTOMOBILE TELEPHON 3 129.067 AUS 39 810 SOUND SYSTEM 129.076 AUS 45 214,216 SELF-LEVELLING DEVICE 2 . ============================================================================================================================== TABLE REAR SPRING - RUBBER BOOT NORMAL SPRINGS ============================================================================================================================== SUM OF POINTS REAR SPRING BOOT: BOOT: WITH BLUE REAR SPRING W/ RED REAR SPRING -45 129 324 14 04 201 325 10 44 201 325 11 44 46-52 129 324 05 04 201 325 09 44 201 325 10 44 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF-LEVELLING DEVICE CODE 214, 216 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD PAD REAR SPRING BLUE REAR SPRING RED -46 129 324 15 04 201 325 10 44 201 325 11 44 47- 129 324 12 04 201 325 09 44 201 325 10 44 ==============================================================================================================================
TO ASCERTAIN THE REAR SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 129.066 AUS 38 329 AUTOMOBILE TELEPHON 3 129.067 AUS 39 810 SOUND SYSTEM 129.076 AUS 45 214,216 SELF-LEVELLING DEVICE 2 . ============================================================================================================================== TABLE REAR SPRING - RUBBER BOOT NORMAL SPRINGS ============================================================================================================================== SUM OF POINTS REAR SPRING BOOT: BOOT: WITH BLUE REAR SPRING W/ RED REAR SPRING -45 129 324 14 04 201 325 10 44 201 325 11 44 46-52 129 324 05 04 201 325 09 44 201 325 10 44 ============================================================================================================================== CHART OF REAR SPRING RUBBER PADS W/SELF-LEVELLING DEVICE CODE 214, 216 ============================================================================================================================== TOTAL OF POINTS REAR SPRING PAD PAD REAR SPRING BLUE REAR SPRING RED -46 129 324 15 04 201 325 10 44 201 325 11 44 47- 129 324 12 04 201 325 09 44 201 325 10 44 ==============================================================================================================================
Description: As required.
8
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 1 (8 mm ). Number of burls: 1 (8mm).
MSRP $7.00
$6.09
MSRP $7.00
$6.09
8
MSRP $9.50
$8.27
8
MSRP $11.50
$9.86
11
MSRP $670.00
$508.00
14
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to spring control arm. Shock absorber to lower control arm m 10x1x60. Shock absorber to spring control arm m 10x1x60. Pitman arm to steering box assembly m10x1x60. Hydropneumatic spring leg to rear axle.
MSRP $42.50
$33.66
MSRP $42.50
$33.66
17
Washer Mercedes-Benz
Mercedes-Benz Description: Refrigerant compressor to support. Bearing cup to bearing bracket.
MSRP $2.70
$2.32
MSRP $2.70
$2.32
20
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M10
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Propeller shaft to transmission. Shock absorber to lower control arm m 10x1. Shock absorber to spring control arm m 10x1. Hydropneumatic spring leg to spring control arm m 10. Shock absorber to frame. Hydropneumatic spring leg to rear axle.
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Propeller shaft to transmission. Shock absorber to lower control arm m 10x1. Shock absorber to spring control arm m 10x1. Hydropneumatic spring leg to spring control arm m 10. Shock absorber to frame. Hydropneumatic spring leg to rear axle.
MSRP $4.40
$3.77
MSRP $4.40
$3.77
23
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to frame. Hydropneumatic spring leg to spring control arm.
MSRP $11.00
$9.28
MSRP $11.00
$9.28
26
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to frame. Shock absorber to frame. Bumper to body.
29
Window Mercedes-Benz
Mercedes-Benz Description: Hydropneumatic spring leg to frame. Shock absorber to frame to 201 320 09 31, 201 326 15 00. Shock absorber to frame to 201 320 12 31, 201 326 19 00. Shock absorber to frame to 124 320 10 31, 124 320 11 31.
35
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M10X1
Diameter: 10mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Front shock absorbers to frame. Bumper to body. Shock absorber to frame m 10x1. Hydropneumatic spring leg to frame m 10x1.
Diameter: 10mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Width across flats: 16mm. Front shock absorbers to frame. Bumper to body. Shock absorber to frame m 10x1. Hydropneumatic spring leg to frame m 10x1.
MSRP $3.70
$3.19
MSRP $3.70
$3.19
